Huawei S5700 Series Switches
Dimensions (H x W x D): Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442.0 mm x 420.0 mm (1.72 in. x 17.4 in. x 16.5 in.) Maximum dimensions (the depth is the distance from ports on the front panel to the handle on the rear panel): 43.6 mm x 442.0 mm x 446.0 mm (1.72 in. x 17.4 in. x 17.6 in.)
Relative humidity: 5% to 95%, noncondensing
PoE: Not supported
Operating temperature: -5°C to +45°C (23°F to 113°F) at an altitude of 0-1800 m (0-5906 ft.) NOTE: When the altitude is 1800-5000 m (5906-16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.). The switch cannot be started when the ambient temperature is lower than 0°C (32°F). The operating temperature of the switch is -5°C to 40°C (23°F to 104°F) when it uses QSFP-100G-ER4 optical module.
Certification: EMC certification Safety certification Manufacturing certification
Availability: > 0.99999
RTC: Supported
Flash: 2 GB in total. To view the available flash memory size, run the display version command.
Storage temperature: -40°C to +70°C (-40°F to +158°F)
Operating altitude: 0-5000 m (0-16404 ft.)
Memory (RAM): 4 GB
Mean time between failures (MTBF): 62.27 years
Rated voltage range: AC input: 100 V AC to 240 V AC, 50/60 Hz High-Voltage DC input: 240 V DC DC input: -48 V DC to -60 V DC
Maximum voltage range: AC input: 90 V AC to 290 V AC, 45 Hz to 65 Hz High-Voltage DC input: 190 V DC to 290 V DC DC input: -38.4 V DC to -72 V DC
Item: Description
Service port surge protection: N/A
Power supply surge protection: Using AC power modules: ±6 kV in differential mode, ±6 kV in common mode Using DC power modules: ±2 kV in differential mode, ±4 kV in common mode
Noise under normal temperature (27°C, sound power): < 65 dB(A)
Mean time to repair (MTTR): 2 hours
Stack ports: Any QSFP+ ports
RPS: Not supported
Maximum power consumption (100% throughput, full speed of fans): 229 W
Typical power consumption (30% of traffic load, tested according to ATIS standard): 126 W
Файлы: https://www.router-switch.com/media/upload/product-pdf/huawei-cloudengine-s5732-h-switches-datasheet.pdf, https://www.router-switch.com/media/upload/product-pdf/quick-check-of-huawei -s5700-enterprise-switches.pdf, https://www.router-switch.com/huawei-s5732-h24s6q-k-datasheet-pdf.html
Next generation CloudEngine S5732-H Series Multi-GE Switches offers either 24 or 48 downlink ports __ up to 10 GE __ alongside four 25 GE uplink ports and either two 40 GE or two 100 GE uplink ports. With this feature set, CloudEngine S5732-H is designed for connecting to Wireless Local Area Network (WLAN) APs in the Wi-Fi 6 era. Based on Huawei's unified Versatile Routing Platform (VRP), the switches boast a range of Intent-Driven Network (IDN) features, including an integrated wireless Access Controller (AC) that can manage up to 1024 wireless Access Points (APs), and a free mobility feature that offers a consistently high-quality user experience.
Quick Spec
Table 1 shows the quick spec.
|
Product Model |
S5732-H24S6Q-K |
|
Memory |
4 GB |
|
Flash memory |
2 GB |
|
Typical power consumption |
126 W |
|
Maximum power consumption |
299W |
Supported Transceivers
Table 2 shows the recommended models.
|
Model |
Description |
|
Huawei Optical Transceiver OMXD30000, SFP+, 10G, Multi-mode Module (850nm, 0.3km, LC) |
|
|
Optical Transceiver, eSFP, GE, Single-mode Module (1310nm, 10km, LC) |
|
|
Transceiver, QSFP+, 1310nm, 41.25Gbps, -7dBm, 2.3dBm, -11.5dBm, LC, SMF, 10 |
|
|
? |
Optical Transceiver, eSFP, GE, Multi-mode Module (850nm,0.5km, LC) |
Compare to Similar Items
Table 3 shows the comparison.
|
Product Model |
||||||
|
Forwarding Performance |
24 Mpps |
42 Mpps |
96 Mpps |
78 Mpps |
132 Mpps |
108 Mpps |
|
Switching Capacity2 |
32 Gbit/s/336 Gbit/s |
56 Gbit/s/336 Gbit/s |
128 Gbit/s/336 Gbit/s |
104 Gbit/s/432 Gbit/s |
176 Gbit/s/432 Gbit/s |
144 Gbit/s/432 Gbit/s |
|
Fixed Ports |
12 x 10/100/1000Base-T ports, 4 x GE SFP ports |
24 x 10/100/1000Base-T ports, 4 x GE SFP ports |
24 x 10/100/1000Base-T ports, 4 x 10 GE SFP+ ports |
48 x 10/100/1000BASE-T ports, 4 x GE SFP ports |
48 x 10/100/1000BASE-T ports, 4 x 10 GE SFP+ ports |
24 x GE SFP ports, 8 x 10/100/1000BASE-T ports, 4 x 10 GE SFP+ ports |
|
PoE+ |
CloudEngine S5735S-L12P4S-A: Supported |
|||||
