YCFJ3 Контроллер Dell PE PERC H810 1-GB RAID

Тип товара: Контроллер<br>
Совместимость: For Dell PowerEdge R320 R420 R520 R620 R720 R720xd R820 T320 T420 T620 ServersFor Dell PowerVault MD1200 MD1220<br>
<br>
Description:Dell PE PERC H810 Internal/External1GB NV (Non-Volatile) Cache Dual-CorePowerPC CPU PCI Express SAS 6Gb/s RAID ControllerFor Dell PowerEdge R320 R420 R520 R620 R720R720XD R820 R830 T320 T420 T620 ServersFor Dell PowerVault MD1200 MD1220Part Number(s)<br>
Dell Part# YCFJ3Dell Part# 0YCFJ3<br>
Note:Please confirm Low Profile or Full Height Bracket<br>
In comments box at checkout. Thank you<br>
<br>
<br>
<br>
<br>
Overview:<br>
The Dell™ PowerEdge™ PERC H810 RAID Controller is for select 12th Generation Dell Servers. The PERC H810 contains all the features of the H710P - with one major difference: the H710P is for your server’s internal drives — up to 32 of them — while the H810 can connect to JBOD - running up to 192 drives. The external RAID option is used for connecting the host server to PowerVault MD1220 and/or MD1200 enclosures. The PERC H810 exploits the potential of SSDs for unsurpassed performance and enterprise-class reliability. The PERC H810 offers external JBOD expansion using up to 192 3 Gb/s and 6 Gb/s and SAS Hard Drives or SSDs.<br>
<br>
Specifications:<br>
CategoryDell Controller<br>
Sub-CategoryController<br>
GenerationPCI-Express<br>
Part NumberYCFJ3<br>
Products ID725814<br>
Device TypeStorage Controller (RAID) - Plug-in Card<br>
Interface TypePCI Express 2.0 x8<br>
Data Transfer RateUp to 6Gb/s per Port<br>
ConnectorsTwo External mini-SAS SFF8088 <br>
Non-Volatile Cache1GB<br>
CacheCade1.1<br>
Battery (Onboard)Yes<br>
Max Hard Drives Supported192<br>
SAS Controller2 x Dual-Core PowerPC<br>
RAID ControllerRAID 0 1 5 6 10 50 60<br>
Operating Voltage+3.3V<br>
<br>
<br>
<br>
<br>
<br>
<br>
<br>
<br>
<br>
<br>
<br>
<br>
<br>
<br>
<br>
<br>
<br>
<br>
<br>
<br>
<br>
<br>
<br>
<br>
<br>
Enlarge Image of Part# YCFJ3
